AT-AR3050S-30
Product information "AT-AR3050S-30"
The AR3050S UTM Firewall consolidates threat protection, application and web control capabilities into a single device - ensuring the security of business communications. Together with advanced routing and switching, the AR3050S integrated security platform is the ideal choice for Internet gateway applications.
The dual-core processor significantly increases throughput and enables simultaneous packet inspection. It is optimized for single-pass low-latency traffic inspection. Security engines and threat signature databases from the industrys leading vendors, with regular updates, provide up-to-the-minute protection against malware, viruses and other cyber-attacks.
- High availability bypass ports allow device redundancy with a single WAN link, reducing ongoing ISP fees. If the Master firewall loses power, traffic is automatically forwarded to the backup device.
- A USB interface supports 3G/4G connectivity, so data transfer can automatically switch to a mobile network when a primary WAN connection becomes unavailable.
- An SD card slot allows easy backup of important files.
- Autonomous Management Framework (AMF) compatibility automates device back-up for plug-and-play recovery.
The dual-core processor significantly increases throughput and enables simultaneous packet inspection. It is optimized for single-pass low-latency traffic inspection. Security engines and threat signature databases from the industrys leading vendors, with regular updates, provide up-to-the-minute protection against malware, viruses and other cyber-attacks.
- High availability bypass ports allow device redundancy with a single WAN link, reducing ongoing ISP fees. If the Master firewall loses power, traffic is automatically forwarded to the backup device.
- A USB interface supports 3G/4G connectivity, so data transfer can automatically switch to a mobile network when a primary WAN connection becomes unavailable.
- An SD card slot allows easy backup of important files.
- Autonomous Management Framework (AMF) compatibility automates device back-up for plug-and-play recovery.
| AC input frequency: | 47/63 Hz |
|---|---|
| AC input voltage: | 90-260 V |
| Built-in processor: | Yes |
| Concurrent connections: | 100000 |
| Connectivity technology: | Wired |
| DHCP client: | Yes |
| DhCP server: | Yes |
| Dimensions (WxDxH): | 425 x 210 x 220 mm |
| Ethernet LAN (RJ-45) ports: | 8 |
| Firewall throughput: | 0.75 Gbit/s, 750 Mbit/s |
| Flash memory: | 4096 MB |
| IPS/IDS throughput: | 220 Mbit/s |
| Internal memory: | 1024 MB |
| Maximum firewall connections per second: | 3600 |
| Multicast support: | Yes |
| Noise level: | 28.4 dB |
| Operating relative humidity (H-H): | 5 - 80% |
| Operating temperature (T-T): | 0 - 50 degC |
| Point-to-point protocol over Ethernet (PPPoE): | Yes |
| Port forwarding: | Yes |
| Power consumption (typical): | 23 W |
| Processor cores: | 2 |
| Processor frequency: | 800 MHz |
| Routing protocols: | BGP4, OSPF, RIP-1, RIP-2 |
| Storage relative humidity (H-H): | 5 - 95% |
| Storage temperature (T-T): | -25 - 70 degC |
| USB 2.0 ports quantity: | 1 |
| VPN throughput: | 0.4 Gbit/s, 400 Mbit/s |
| WAN connection: | Ethernet (RJ-45) |
| Weight: | 1.7 kg |
