8x 10/100/1000T 2x 1G/10G SFP+ Industrial Ethernet Layer 2+ Switch PoE++ Support
Product information "8x 10/100/1000T 2x 1G/10G SFP+ Industrial Ethernet Layer 2+ Switch PoE++ Support"
Industrial Ethernet Layer 2+ PoE++ Switches with 10G uplinks
Ruggedized switches built for enduring performance in harsh environments. Power over Ethernet (PoE++) connects and powers environmental, system control, and other key IIoT devices for a reliable and high-performing solution and 10G fiber uplinks ensure capacity for demanding edge applications. The IE220 Series enables safety, security, and smooth operation for building automation, intelligent transportation, and smart city networks.
Ruggedized switches built for enduring performance in harsh environments. Power over Ethernet (PoE++) connects and powers environmental, system control, and other key IIoT devices for a reliable and high-performing solution and 10G fiber uplinks ensure capacity for demanding edge applications. The IE220 Series enables safety, security, and smooth operation for building automation, intelligent transportation, and smart city networks.
| 10G support: | No |
|---|---|
| ARP inspection: | Yes |
| Access Control List (ACL): | Yes |
| Authentication: | MAC-based authentication, Port-based authentication |
| BPDU filtering/protection: | Yes |
| Basic switching RJ-45 Ethernet ports quantity: | 8 |
| Basic switching RJ-45 Ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity: | 2 |
| Configuring Location Settings (CLI): | Yes |
| DHCP features: | DHCP client, DHCP snooping |
| DIN rail mounting: | Yes |
| Depth: | 137 mm |
| Flash memory: | 128 GB |
| Flow control support: | Yes |
| Full duplex: | Yes |
| Gigabit Ethernet (copper) ports quantity: | 10 |
| Height: | 155 mm |
| Housing material: | Aluminium, Metal |
| IGMP snooping: | Yes |
| Input voltage: | 37 - 57 V |
| Internal memory: | 512 GB |
| International Protection (IP) code: | IP30 |
| Jumbo frames support: | Yes |
| Link aggregation: | Yes |
| MAC address table: | 16000 entries |
| Management protocols: | SNMPv1/v2c/v3 |
| Multicast support: | Yes |
| Networking standards: | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.3bt |
| Number of VLANs: | 4094 |
| Packet buffer memory: | 2 MB |
| Power consumption (max): | 18.5 W |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet 4PPoE (PoE++) ports quantity: | 2 |
| Power over Ethernet plus (PoE+) ports quantity: | 8 |
| Power source: | DC/PoE |
| Product colour: | Grey |
| Quality of Service (QoS) support: | Yes |
| Rack mounting: | No |
| Security algorithms: | 802.1x RADIUS |
| Switching capacity: | 56 Gbit/s |
| Switch layer: | L2 |
| Switch type: | Managed |
| System event log: | Yes |
| Throughput: | 41.7 Mpps |
| Traffic classification: | Yes |
| Traffic shaping: | Yes |
| USB 2.0 ports quantity: | 1 |
| VLAN support: | Yes |
| Wall mountable: | Yes |
| Web-based management: | Yes |
| Width: | 65 mm |
