24-port 10/100/1000T Ethernet line card
Product information "24-port 10/100/1000T Ethernet line card"
The Allied Telesis AT-SBx81GS24a line card provides 24 SFP Gigabit ports, providing a host of flexible connectivity options.
The ability to aggregate a widely distributed network where access devices may be in remote buildings is an excellent solution for multi-building campus environments. The option to mix short-haul and long-haul SFP optical devices in a single line card allows maximum flexibility in the placement of access switches, whether they are located locally or even city-wide.
The ability to aggregate a widely distributed network where access devices may be in remote buildings is an excellent solution for multi-building campus environments. The option to mix short-haul and long-haul SFP optical devices in a single line card allows maximum flexibility in the placement of access switches, whether they are located locally or even city-wide.
| Access Control List (ACL): | Yes |
|---|---|
| Buffer size per port: | 1.5 MB |
| Certification: | EN55024, EN61000-3 UL, cUL, TUV RoHS |
| Compatibility: | Allied Telesis SwitchBlade x8100 |
| Copper ethernet cabling technology: | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Country of origin: | Indonesia |
| Dimensions (WxDxH): | 207 x 313 x 41 mm |
| Ethernet LAN (RJ-45) ports: | 24 |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Ethernet interface type: | Gigabit Ethernet |
| Flow control support: | Yes |
| Harmonized System (HS) code: | 85176990 |
| Jumbo frames support: | Yes |
| Link aggregation: | Yes |
| Networking standards: | IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Operating altitude: | 0 - 3048 m |
| Operating relative humidity (H-H): | 5 - 90% |
| Operating temperature (T-T): | 0 - 40 degC |
| Power consumption (typical): | 34.4 W |
| Quality of Service (QoS) support: | Yes |
| Queues per port: | 8 |
| Safety: | UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1 |
| Security algorithms: | 802.1x RADIUS, SSH-2 |
| Service level: | 3 |
| Storage relative humidity (H-H): | 5 - 95% |
| Storage temperature (T-T): | -25 - 70 degC |
| Weight: | 1.1 kg |
