10/100/1000BASE-T ports x 24 (Combo)-SFP slot x 24 (Combo)-SFP/SFP+ slots x 4 Console port x 1 (RJ45)-Dual PS slot - Dedicated Stacking port x 2 (Rear panel)
Product information "10/100/1000BASE-T ports x 24 (Combo)-SFP slot x 24 (Combo)-SFP/SFP+ slots x 4 Console port x 1 (RJ45)-Dual PS slot - Dedicated Stacking port x 2 (Rear panel)"
The Allied Telesis x930-28GSTX features 24 Gigabit combo ports with 4 10 Gigabit uplinks, providing the ability to mix copper and fiber connectivity for fully flexible deployment. Long-distance stacking of up to 8 units supports distributed environments, and Allied Telesis Management Framework (AMF) and Wireless Manager provide unified network management for your entire wired and wireless infrastructure.
| 10G support: | Yes |
|---|---|
| AC input frequency: | 47/63 Hz |
| AC input voltage: | 90 - 260 V |
| ARP inspection: | Yes |
| Basic switching RJ-45 Ethernet ports quantity: | 24 |
| Basic switching RJ-45 Ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity: | 24 |
| DHCP features: | DHCP server, DHCPv6 relay, DHCPv6 server, DHCP client |
| Depth: | 420 mm |
| Expansion module support: | Yes |
| Firmware upgradeable: | Yes |
| Flash memory: | 256 GB |
| Full duplex: | Yes |
| Heat dissipation: | 329 BTU/h |
| Height: | 44 mm |
| IGMP snooping: | Yes |
| Internal memory: | 2048 MB |
| LED indicators: | Yes |
| Latency (1 Gbps): | 3.7 micro second |
| Latency (10 Gbps): | 2.6 micro second |
| Link aggregation: | Yes |
| MAC address table: | 64000 entries |
| MIB support: | Y |
| Memory type: | DDR-SDRAM |
| Multicast MAC address table: | 2000 entries |
| Multicast support: | Yes |
| Noise level: | 39.7 dB |
| Number of VLANs: | 4094 |
| Operating altitude: | 0 - 3048 m |
| Operating relative humidity (H-H): | 5 - 90% |
| Operating temperature (T-T): | 0 - 50 degC |
| Policy-based routing: | Yes |
| Port mirroring: | Yes |
| Power consumption (typical): | 97 W |
| Power over Ethernet (PoE): | No |
| Product colour: | Grey |
| Quality of Service (QoS) support: | Yes |
| Rack mounting: | Yes |
| Routing entries: | 2000 |
| SFP+ module slots quantity: | 4 |
| Safety: | UL60950-1, CAN/CSA-C22.2 No.60950-1-03, EN60950-1, EN60825-1, AS/NZS60950.1, UL, cUL |
| Security algorithms: | 802.1x RADIUS |
| Spanning tree protocol: | Yes |
| Stackable: | Yes |
| Storage relative humidity (H-H): | 5 - 95% |
| Storage temperature (T-T): | -25 - 70 degC |
| Switching capacity: | 288 Gbit/s |
| Switch layer: | L3 |
| Switch type: | Managed |
| System event log: | Yes |
| Throughput: | 214.3 Mpps |
| Traffic classification: | Yes |
| VLAN support: | Yes |
| Virtual LAN features: | Private VLAN |
| Web-based management: | Yes |
| Weight: | 5.1 kg |
| Width: | 440 mm |
